Product Details:
Place of Origin: China
Brand Name: CCSC
Certification: API 6A
Model Number: Adjustable choke cage and sleeve type
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: plywood box
Delivery Time: 30-40days
Payment Terms: T/T

CCSC Oil And Gas Choke Valve Flange Connected Working Pressure 2,000psi – 20,000ps

Description
Size: 2-4 Inch Working Pressure: 2,000psi – 20,000ps
Material Class: AA-EE Connection Type: Flange,union, Thread
Processing Type: Forging Material: Alloy Steel
Media: Oil, Gas
High Light:

actuated choke valve

,

positive choke valve



API 6A high pressure Adjustable Cage Choke/Sleeve Choke with size range from 2-4 inch



Cage and sleeve choke is often used for control flow in severe condition instead of triditional needle and seat choke, the cage and sleeve choke is designed and manufactured in accordance with API 6A and API 16C standard, the cage and sleeve are completely made by Tungsten Carbide alloy, and the size is adjustable by increment of 1/64".

We have all range sizes and pressure ratings cage and sleeve choke for clients' demend.



Cage and sleeve choke Feature:

  • 1. Manufactured and tested in accordance with API 6A.
  • 2. Carbide alloy is embedded into cage and sleeve..
  • 3. Flow adjustment is indicated on a measuring scale.
  • 4. Control sleeve and seat sealing surfaces are not directly exposed to the high velocity flow.
  • 5. Max orifice:1"-3".


Available Specication

cage and sleeve choke
Bore Size 2-4 inch
Working Pressure 2,000psi – 20,000ps
Material Class AA-EE
Connection type flange,union, thread


Cage and sleeve Choke inquiry information

Customers may customize their purchase through the following data:
• Working Pressure
• Type of Connection
• Size & Max. Orifice
• Material Class
